Product Details:
Payment & Shipping Terms:
|
| Material: | Pvc | Surface: | Asa |
|---|---|---|---|
| Width: | 1050mm,1040mm | Effective Width: | 960mm |
| Thickness: | 2.3mm 2.5mm 2.8mm 3.0mm 4.0mm 5.0mm | Color: | Brick Red, Terracotta,yellow ,dark Green,dark Blue |
| Weight: | 4.5kg To 5.8kg Per Sqm | Length: | Customize |
| Origin: | China | Application: | Villa,residential Roof |
| Highlight: | 3 Layers Pvc Roof Tiles,Asa Coated Pvc Roof Tiles,2.8mm Thickness Pvc Roof Tiles |
||
Factory 3 layers pvc roof tiles heat-insulation types of roofing sheets
|
Tech Date of the Synthetic Resin Tiles
|
||||
|
Tensile strength
|
42.6
MPa
|
Chemical resistance properties
|
Acetic aced 10%(physical volume ratio)
|
|
|
High-low temperature change
|
-0.11%
|
Ether 70% (physical volume ratio)
|
||
|
Vertical burning
|
FV-0
|
Ethylene-blue 1% (weight ratio)
|
||
|
Oxygen index
|
40%
|
NaOH 10% (weight retio)
|
||
|
Water absorption rate
|
0.05%
|
Hypochlorous Natrium 15% (weight retio)
|
||
|
Nail force
|
46N
|
|
60°C,6h no deformation no viscousness
|
|
|
Flexural load
|
800N no crack
|
Cold-resistance
|
-35°C,6h, no crack in surface
|
|
|
Flexural strength
|
77 MPa
|
|
||
Specification:
| Product Name | Asa Spanish Pvc Roof Tile |
| Brand | Yiquan |
| Place of Origin | Foshan city,Guangdong province,China(Mainland) |
| Material | Acrylonitrile Styrene acrylate copolymer,Polyvinyl chloride, Calcium powder,other chemical materials |
| Guarantee | 25 years |
| Certification | ISO9001 / SGS / CE |
| Minimum Order Quantity | 1000 square meter |
| Delivery Time | Within 10 days |
| Supply Ability | We have 10 produce lines,about 100 square meter per day |
| Payment Terms | T/T |
| Package | Pallet or PE bag |
| Port | Guangzhou / Shenzhen / Foshan |
| Application | Villa roofing,House roofing,Garden,Grange,Container house, Flat to Slope Project,Etc |
| Overall Width | 1050mm |
| Effective Width | 960mm |
| Thickness | 2.3mm / 2.5mm / 2.8mm / 3.0mm/3.5mm/4.0mm/4.5mm/4.8mm/5.0mm |
| Length | 219mm by times |
| Color | Orange / Red / Grey / Sky blue / Dark green/Golden yellow/Chocolate Brown |
| Wave Spacing | 160mm |
| Wave Height | 30mm |
| Section Length |
219mm
|
